Hikvision AX PRO Series DS-PS1-E-WB Wireless Outdoor Sounder

🚨 Hikvision AX PRO Wireless Outdoor Sounder Security Solution

The Hikvision DS-PS1-E-WB (part of the Hikvision AX PRO wireless intrusion series) is a high-performance outdoor wireless siren designed to provide visible and audible deterrence. Equipped with Hikvision’s Tri-X two-way wireless protocol, AES-128 encryption, and multi-tone sound output, it ensures rapid notification during security incidents.

🌟 Key Product Features

• 110 dB High-Decibel Alarm: Emits loud, distinct sound alerts for 3 specific alarm scenarios: Intrusion, Fire, and Panic.
• High-Visibility LED Strobe: Integrated red and blue flashing LED strobe light provides visual confirmation of active alerts day or night.
• Tri-X Two-Way Wireless Communication: Ensures secure long-range RF transmission (up to 1.6 km in open areas) with AES-128 encryption.
• Frequency Hopping Against Jamming: Automatically shifts frequencies to maintain stable transmission against wireless interference.
• Dual Tamper Protection: Features both front and rear tamper switches to immediately alert the system if the unit is opened or detached from the wall.
• Flexible Power Options: Runs on 4× CR123A batteries (included, up to 3 years lifespan) or optional 12 VDC external wiring.
• IP65 Weatherproof Enclosure: Heavy-duty PC + ABS plastic construction designed to withstand extreme outdoor weather conditions.
• Full Remote App Configuration: Fully configurable via the Hik-Connect mobile app for tone length, volume levels, and arming sounds.

Active Deterrence & Wireless Signal Stability:

Audible & Optical Deterrence: Combining a 110 dB wailing alarm with high-intensity LED flashes creates immediate physical deterrence before intruders enter your premises.

Encrypted Two-Way Communication: Built specifically for the Hikvision AX PRO hub platform, the sounder constantly verifies signal integrity and battery status back to the main control unit.

Instant Smartphone Notifications: Receive push notifications on your phone via Hik-Connect whenever an alarm or tamper event is detected.

Best For:

• Residential Property Entrances: Mount on front facades or garages to alert neighbors and scare away intruders immediately.
• Commercial Premises & Storefronts: Provides loud 110 dB audible warning during after-hours break-in attempts.
• Remote Outbuildings & Sheds: Long-range Tri-X wireless signal connects reliably to AX PRO hubs across large yards or driveways.
• Perimeter Fence Lines: Acts as a visible security visual marker while protecting property boundary lines.

Why Choose the Hikvision DS-PS1-E-WB?

Many wireless sirens suffer from short battery life or unreliable signal connections. The Hikvision AX PRO DS-PS1-E-WB solves this using Tri-X two-way wireless technology with frequency hopping and AES-128 encryption, delivering transmission ranges up to 1.6 km. Its dual front and rear tamper switches ensure immediate alerts if vandalism is attempted, while the IP65-rated housing withstands harsh weather conditions. Combined with a 3-year battery lifespan and our complete 3-year local warranty, it provides dependable perimeter alarm protection.

📋 Technical Specifications:

📦 What’s Included in the Service Package:

• 1× Hikvision AX PRO DS-PS1-E-WB Wireless Outdoor Sounder
• 4× CR123A Batteries (Pre-installed / Included)
• 1× On-Site Installation & Wall Mounting
• 1× Pairing & Integration with Hikvision AX PRO Alarm Hub
• 1× Mobile App Linking (Hik-Connect on iOS / Android)
• 1× 3-Year Service & Product Warranty Card

📄 Documentation & Download Links:

• 📄 Official Datasheet: Hikvision DS-PS1-E-WB Wireless Sounder Datasheet (PDF)
• 📖 User Guide: Hikvision DS-PS1 Wireless Outdoor Sounder User Guide

FAQs

1. What is the Hikvision DS-PS1-E-WB used for?
   The DS-PS1-E-WB is used as a wireless outdoor sounder for compatible Hikvision AX PRO alarm systems. It provides an external audible warning when the alarm system activates during a configured intrusion or alarm event.
2. Is the DS-PS1-E-WB wired or wireless?
   The DS-PS1-E-WB is a wireless sounder designed for compatible AX PRO systems. It is useful where an external sounder is needed but running a wired siren cable back to the hub is not practical.
3. Does this sounder work with AX PRO?
   Yes. The DS-PS1-E-WB is part of the Hikvision AX PRO wireless alarm range and should be used with compatible AX PRO hubs and supported system configurations.
4. Can it be installed outdoors?
   Yes. The DS-PS1-E-WB is designed as an outdoor sounder. The installer should still consider the mounting location, weather exposure, tamper protection, signal strength and service access before installation.
5. When should I choose a wireless outdoor sounder?
   Choose a wireless outdoor sounder when the site uses AX PRO wireless equipment and an external audible alarm warning is required without running new siren cabling. For hardwired alarm systems, a wired external siren may be more suitable.
6. Where should the sounder be mounted?
   The sounder is commonly mounted high on an external wall where it is visible, difficult to reach and able to project alarm sound effectively. For systems supplied through Security Wholesalers, signal testing and tamper setup should be completed before final mounting.
7. Does this replace the AX PRO hub?
   No. The DS-PS1-E-WB does not replace the AX PRO hub. It works as a wireless outdoor sounder within a compatible AX PRO alarm system and responds to configured alarm events.
8. What should be checked before installation?
   Before installation, confirm AX PRO compatibility, wireless signal strength, mounting height, outdoor exposure, tamper configuration, battery or power requirements, siren duration settings, local noise requirements and whether the site also needs indoor sounders or additional repeaters.
